Still, customers (or a lack thereof) remain the gating factor for 14A production. Intel told investors in January that it’s got two prospective customers evaluating 14A test chips , and its SEC filings still warn that without a significant external customer, it “may pause or discontinue” 14A, successor nodes, and various manufacturing expansion projects.
Elon Musk said in April that his planned TeraFab project — the first named taker for the node — will use 14A process technology to make AI chips, though test production is expected to be years out. This also isn’t such a big win in terms of the volume commitment Intel’s filings say it needs for 14A to be viable. At the time of writing, 14A’s next and arguably most critical milestone is the 14A v0.9 PDK, which Tan says will reach external customers in October .
"The Holy Grail is v0.9 PDK. Right now, we are looking at October to [hand it to] the outside customer. Internal customer will be earlier, so that we make sure that we really clean the pipe, make sure that we are doing right, make sure that we can sell with good quality."
Launched in 2023, Fab 34 in Leixlip is Intel's only EUV-class site in Europe, producing Intel 4 and Intel 3 silicon for Core Ultra and Xeon 6 parts. In 2024, Apollo-managed funds paid $11.2 billion for a 49% interest in the joint venture entitled to the fab's output, a deal that gave Intel a much-needed cash injection at the time.
In April this year, Intel bought that stake back for $14.2 billion — at a premium of roughly 27% — funded from cash and about $6.5 billion in new debt issuance. Apollo walked away with around $3 billion in return for two years of exposure, and Intel paid a nine-figure annual cost of capital to reclaim needed wafer revenue.
“Flexibility and alignment are core to how we approach relationships as a long-term, solutions-oriented capital partner, and we are pleased to facilitate this transaction in support of Intel's evolving strategic and operational priorities,” said Apollo Partner Jamshid Ehsani at the time.
Wroclaw's $4.6 billion assembly and test plant was canceled the same day, and Costa Rica's assembly and test operations were consolidated into Vietnam and Malaysia. Fab 38 in Kiryat Gat, Israel, the planned $25 billion expansion announced in 2023 with $3.5 billion in Israeli government backing, has been paused for the last two years , with no restart announced. Every leading-edge wafer Intel produces for the foreseeable future will come therefore come from three U.S. states and one campus in Ireland.
Fab 9 in Rio Rancho, New Mexico, a $3.5 billion conversion that opened in January 2024, is the only high-volume Foveros 3D stacking site in the United States. Foveros is the packaging behind every tiled Intel design since Meteor Lake, bonding compute, graphics, and I/O dies vertically rather than laying them side by side, and it is integral to the stacked Clearwater Forest parts now ramping on 18A.
Intel runs it alongside the neighboring Fab 11x as a single co-located operation, which EVP Keyvan Esfarjani called “the only U.S. factory producing the world's most advanced packaging solutions at scale.” The buildout created hundreds of Intel jobs and more than 3,000 construction roles, and the campus later drew a further $500 million in CHIPS funding for modernization.
The $7 billion Penang complex in Malaysia , placed on indefinite hold in early 2025, has been revived: the buildout is now 99% complete, and first-phase assembly and test operations are due to begin later this year, according to Malaysian Prime Minister Anwar Ibrahim, following an earlier briefing with Tan. Intel has also outsourced EMIB production to Amkor's Songdo facility in South Korea, and its next-generation EMIB-T packaging rolls out across production fabs this year .
With Magdeburg and the Penang delay having stripped packaging options elsewhere, Rio Rancho is now the load-bearing U.S. node for the back-end work that makes Intel's entire chip roadmap possible.
Intel’s 14A commitment window and the cutoff for tax credits both converge in the second half of this year. Tan’s stated expectation is that customers make firm supplier decisions between the second half of 2026 and the first half of 2027, with results from the upcoming October PDK potentially being the trigger for those decisions.
On June 8th, Cadence announced a multi-year agreement with Intel Foundry to co-optimize designs for 14A and deliver production-ready process design kits. This is exactly the EDA groundwork that needs to be in place before any fabless customer can commit volume, and a committed volume customer will be what unlocks acceleration at Ohio and gives Fab 62 a job. The alternative, per Intel, is to cancel 14A altogether.
Unlike the customer deadline set by Intel, the tax deadline can’t slip. The so-called One Big Beautiful Bill Act raised the Section 48D advanced manufacturing investment credit from 25% to 35% in July last year, but the law's termination clause is unchanged: the credit doesn't apply to “property the construction of which begins after December 31, 2026.”
Treasury rules let a physical-work test or a 5% spend safe harbor establish a construction start, so Intel has roughly six months to break ground on any new shells, in Ohio, Arizona, or Oregon, that it wants the U.S. government to part-fund. The government, of course, has been a shareholder since August, when $5.7 billion in unpaid CHIPS grants from Intel's $7.86 billion award and $3.2 billion in Secure Enclave funds were converted into a 9.9% equity stake.
Ultimately, we’re going to be watching for three things before January: a named 14A customer with a volume commitment; a construction-start announcement timed to beat the credit deadline; and 18A yield milestones that free up the Arizona capacity Intel’s currently sitting on.
