Intel is also adding a new VT (threshold voltage) pair to its lineup. Typically, we see four flavors of VT pairs: HVT, SVT, LVT, and ULVT, noting high, standard, low, and ultra-low threshold voltage, respectively. The lower the threshold voltage, the less power a transistor needs to activate, and therefore the more power it leaks. So, ULVT transistors are the most performant, but they leak the most power, while HVT transistors are the least performant but leak the least amount of power. Chip designers need to balance these different flavors of threshold voltage for their application.

The new VT pair adds another option: ULVTLL, or Ultra-Low Voltage Threshold Low Leakage. It lives between ULVT and LVT, offering better performance than LVT but lower leakage than ULVT. Like the new transistor design, it gives designers more flexibility when designing a chip for 18A-P.

In addition to the expanding 18A-P’s capabilities, Intel says the revision comes with a 20% to 40% improvement in thermal resistance, as well as a 10% to 30% improvement in via resistance at “perf critical layers.” The reduction in thermal resistance comes from grinding the wafer down with advanced EDA tools for better thermal conductivity.

Intel 18A is currently ramping in two U.S. fabs, and although the company has taken some heat for poor 18A yields , Intel says that defect rates continue to drop along with its expectations. 18A is being used already in Panther Lake and Xeon 6+, and Intel is reportedly in talks with Apple and Nvidia to build on 18A, as well.
