Several more carefully targeted deposition and erosion steps later, we are ready for the metallization of the silicon chip. A tiny stencil is used to accurately spray the sample with aluminum, the excess stripped away, and the fully layered and formed chip is at last ready for some tests!
The freshly fabricated DRAM cells are so small that wires can’t be used to hook them up to test machinery by the DIYers. Micromanipulator probes are precisely positioned instead. The good news is that Dr. Semiconductor was pleased with his finished DRAM chips, as cells were measured to offer a hobbyist sweet spot of 12pF capacitance.
At the end of the video, the doc teases that he’s going to build on this significant, though admittedly small-scale, achievement. He’s looking to prepare a much larger array of finished memory cells and says that they will be prepared to “hook up to a PC.” Stay tuned for the PC-scale practical implementation, folks.
We reported on Dr. Semiconductor's creation of this garden shed-based cleanroom back in March.
